Parent Layer: 1K

Name: Waterlines_1K

Display Field: gnis_name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: River and Stream lines that represent flowlines and cartographic features such as stream centerlines and river banks.

Service Item Id: 1bf52f17e8fe441db600121673ef6feb

Copyright Text:

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 8000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Effective Min Scale: 1950

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Extent:

XMin: -1.1211880442725953E7
YMin: 3389301.4064264395
XMax: -1.0921110584088096E7
YMax: 3595776.7516576545
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [199, 228, 237, 255]
Width: 4
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementCenterAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [109, 175, 194, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: baseline
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Verdana
Font Style: italic
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: false
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• gnis_id ( nullable: true, length: 10, alias: Geographic Names Information System ID, type: esriFieldTypeString )
• gnis_name ( nullable: true, length: 65, alias: Name from Geographic Names Information System, type: esriFieldTypeString )
• lengthkm ( nullable: true, alias: Length in Kilometers, type: esriFieldTypeDouble )
• reachcode ( nullable: true, length: 14, alias: Reach, type: esriFieldTypeString )
• ftype ( nullable: true, length: 30, alias: Feature Type, type: esriFieldTypeString )
• fcode ( nullable: true, alias: Feature Code, type: esriFieldTypeInteger )
• visibilityfilter ( nullable: true, alias: Visibility Filter, type: esriFieldTypeInteger )
• nhdplusid ( nullable: true, alias: NHDPlus ID, type: esriFieldTypeDouble )
• streamleve ( nullable: true, alias: Stream Level, type: esriFieldTypeSmallInteger )
• streamorde ( nullable: true, alias: Stream Order, type: esriFieldTypeSmallInteger )
• areasqkm ( nullable: true, alias: Catchment Area in Square Kilometers, type: esriFieldTypeDouble )
• totdasqkm ( nullable: true, alias: Total Drainage Area in Square Kilometers, type: esriFieldTypeDouble )
• maxelevraw ( nullable: true, alias: Maximum Elevation, type: esriFieldTypeDouble )
• minelevraw ( nullable: true, alias: Minimum Elevation, type: esriFieldTypeDouble )
• slope ( nullable: true, alias: Slope, type: esriFieldTypeDouble )
• slopelenkm ( nullable: true, alias: Slope Length in Kilometers, type: esriFieldTypeDouble )
• qema ( nullable: true, alias: Gage Adjusted Mean Annual Flow, type: esriFieldTypeDouble )
• vema ( nullable: true, alias: Gage Adjusted Mean Annual Velocity, type: esriFieldTypeDouble )
• qgadjma ( nullable: true, alias: Gage Flow Adjustment, type: esriFieldTypeDouble )
• gageadjma ( nullable: true, alias: Is Mean Annual Flow Gage Adjusted, type: esriFieldTypeSmallInteger )
• gageqma ( nullable: true, alias: Mean Annual Gage Flow, type: esriFieldTypeDouble )
• PopupTitle ( nullable: true, length: 75, alias: Pop-up Title, type: esriFieldTypeString )
• PopupSubtitle ( nullable: true, length: 75, alias: Pop-up Subtitle, type: esriFieldTypeString )
• Shape_Length ( nullable: true, alias: Shape_Length, type: esriFieldTypeDouble )

Supported Operations:   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
